Camera IP 2.0 MP SAMSUNG WISENET SNB-6005/KAP

 Camera IP 2.0 MP SAMSUNG WISENET SNB-6005/KAP

 Camera IP 2.0 MP SAMSUNG WISENET SNB-6005/KAP cho hình ảnh rõ nét ở điều kiện ánh sáng tối hoàn toàn, SNB-6005P có độ phân giải 2M Full HD nên phù hợp lắp đặt ở nhiều vị trí khác nhau như nhà xưởng, kho, siêu thị, trung tâm thương mại, tòa nhà và các giải pháp đảm bảo an ninh khác.

 Camera IP 2.0 MP SAMSUNG WISENET SNB-6005/KAP có thông số kỹ thuật:

• Cảm biến hình ảnh: 1/1.9 inch CMOS
• Chuẩn nén hình ảnh: H.264, Dual stream
• Độ phân giải: 2 Megapixel (1920 x 1080)
• Độ nhạy sáng: Color: 0.03Lux (1/30sec, F1.2, 50IRE), 0.015Lux (1/30sec, F1.2, 30IRE). B/W: 0.003Lux (1/30sec, F1.2, 50IRE), 0.0015Lux (1/30sec, F1.2, 30IRE)
• Chức năng quan sát Ngày và Đêm (ICR)
• Chức năng chống sương mù Defog
• Chức năng giảm nhiễu số 2D+3D
• Chức năng điều chỉnh độ lợi AGC
• Chức năng lọc nhiễu kỹ thuật số Digital DNR (Dynamic Noise Reduction)
• Chức năng phát hiện chuyển động: Off/ On (4ea 4 points polygonal zones)
• Chức năng vùng riêng tư: Off / On (32 zones of rectangular)
• Chức năng Simple Focus
• Đa ngôn ngữ
• Nguồn điện cung cấp: 24/VAC,12/VDC, PoE
• Chức năng cấp nguồn qua mạng PoE
• Kích thước: 73.1 x 66.6 x 147.8mm
• Trọng lượng SNB-6005/KAP: 430g

• Video
  Imaging Device	1/1.9 inch CMOS
  Effective Pixels	1,952(H) x 1,241(V)
  Scanning System	Progressive
  Min. Illumination	Color: 0.03 Lux (1/30sec, F1.2, 50IRE), 0.015Lux (1/30sec, F1.2, 30IRE)
  	B/W: 0.003 Lux (1/30sec, F1.2, 50IRE), 0.0015Lux (1/30sec, F1.2, 30IRE)
  S / N Ratio	50dB
  Video Output	CVBS: 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation
  	DIP connector type
  Lens
  Focus Control	Simple focus (Motorized V/F) / Manual,
  	Remote control via network, Button control (Manual, Simple focus)
  Lens Type	Manual/ DC auto iris, P-Iris
  Mount Type	C / CS
  Operation
  Camera Title	Off / On (Displayed up to 45 characters)
  Day & Night	Auto (ICR) / Color / B/W / External / Schedule
  Backlight Compensation	Off / BLC / WDR
  Wide Dynamic Range	120dB
  Contrast Enhancement (DWDR)	SSDR (Off / On)
  Digital Noise Reduction	SSNRIII (2D+3D noise filter) (Off / On)
  Digital Image Stabilization	Off / On
  Motion Detection	Off / On  (4 zones with 4 points polygonal)
  Privacy Masking	Off / On (32 zones of rectangular)
  Gain Control	Off / Low / Middle / High/ Manual
  White Balance	ATW / AWC / Manual / Indoor / Outdoor
  Electronic Shutter Speed	Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec)
  Flip / Mirror	Off / On
  Intelligent Video Analytics	Tampering, Virtual line, Enter / Exit, (Dis)Appear, Audio detection, Face detection – Support metadata
  Alarm I/O	Input 1ea / Output 1ea
  Remote Control Interface	RS-485
  RS-485 Protocol	Samsung-T/E, Pelco-P/D, Sungjin, Panasonic, Honeywell, AD, Vicon, GE, Bosch
  Alarm Triggers	Motion detection, Tampering, Audio detection, Face detecton, Video analytics, Alarm input, Network disconnection
  Alarm Events	File upload via FTP and E-mail, Notification via E-mail, TCP and HTTP  Local storage (SD/SDHC/SDXC) recording at Network disconnected & Event (Alarm triggers) or NAS recording at event (Alarm triggers), External output
  Network
  Ethernet	RJ-45 (10/100/1000BASE-T)
  Video Compression Format	H.264 (MPEG-4 part 10/AVC): Main / Baseline / High , MJPEG
  Resolution	1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 720 x 576, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180
  Max. Frame rate	H.264: Max. 60fps@the other resolutions
  	MJPEG: Max. 15fps@1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768
  	Max. 30fps@800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 18
  Smart Codec	Manual mode (Area-based: 5ea), Face detection mode
  Video Quality Adjustment	H.264: Target bitrate level control, MJPEG: Quality level control
  Bitrate Control Method	H.264: CBR or VBR, MJPEG: VBR
  Streaming Capability	Multiple streaming (Up to 6 profiles)
  Audio In	Selectable (Mic in / Line in) (Built-in mic)
  	Supply voltage: 2.5VDC (4mA), Input impedance: approx. 2K Ohm
  Audio Out	Line out (3.5mm stereo mini jack), Max output level: 1Vrms
  Audio Compression Format	G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz. G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
  Audio Communication	Bi-directional audio
  IP	IPv4, IPv6
  Protocol	TCP/IP, UDP/IP, RTP(UDP), RTP (TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
  Security	HTTPS(SSL) login authentication, Digest login authentication IP address filtering, User access log, 802.1x authentication
  Streaming Method	Unicast / Multicast
  Max. User Access	15 users at unicast mode
  Edge Storage	SD/SDHC/SDXC – Motion images recorded in the SD/SDHC/SDXC memory card can be downloaded. NAS (Network Attached Storage)
  Application Programming Interface	ONVIF profile S, SUNAPI (HTTP API), SVNP 2.0, Wisenet Open Platform
  Webpage Language	English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian,  Hungarian, Greek
  Web Viewer	Supported OS : Windows XP / VISTA / 7 / 8, MAC OS X 10.7
  	Supported Browser: Microsoft Internet Explorer (Ver. 8 ~ 11).
  	Mozilla Firefox (Ver. 9 ~ 19), Google Chrome (Ver. 15 ~ 25).
  	Apple Safari (Ver. 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7). Mac OS X only
  Central Management Software	SmartViewer, SSM
  ELECTRICAL
  Input Voltage / Current	24VAC ±10%, 12VDC ±10%, PoE (IEEE802.3af, Class3)
  Power Consumption	Max. 11.44W (24VAC, 50 ~ 60Hz), Max. 10.1W (12VDC), Max. 11.1W (PoE, Class3)
  Color / Material	Black, Ivory / Aluminium
  Dimensions	73.1 x 66.6 x 147.8mm
  Weight SNB-6005/KAP	430g
